General-Purpose Water-to-Water HX
APOLLO Brazed Plate Heat Exchanger (BPHX)
A general-purpose water-to-water heat exchanger that isn't tied to one specific MBTEK product line — it's used across heat pump, boiler, chiller, refrigeration, and general hydronic system applications wherever two water loops need to exchange heat without mixing.
Size
10 x 20"
Plate
30
$1,719.75
$1,37520% OFF
Shipping$241Free
Save 20%
- Free shipping
- Secure checkout
Need help choosing?
Product details
- General-purpose water-to-water heat exchanger
- Fully brazed construction
- 316L stainless steel body with 99.9% copper braze
- Three port-size options scale with plate count
Brazed Plate Heat Exchanger (BPHX) – Compact High-Efficiency Heat Exchanger
Compact and highly efficient heat exchanger designed for demanding HVAC, hydronic, and industrial applications, featuring a gasket-free brazed construction for durability and reliability.
Key Benefits
- Compact and lightweight design ideal for space-constrained installations
- High thermal efficiency with turbulent flow for maximum heat transfer
- Leak-proof brazed construction with no gaskets or maintenance required
- Corrosion-resistant materials for long service life
- Handles high pressure and extreme temperatures
- Versatile use across HVAC, refrigeration, and hydronic systems
- Customizable configurations with different plate quantities
Specifications
- Material: 316L Stainless Steel + 99.9% Copper
- Ports:
- 5" x 12": 1 1/4" Female NPT
- 10" x 20": 2" Female NPT
- 12" x 31": 3" Female NPT
- Plate Quantity: 30 / 60 / 100
- Design Pressure (Max): 435 PSI
- Test Pressure (Min): 652 PSI
- Design Temperature: -256°F to 437°F
Compatibility
Suitable for heat pumps, boilers, chillers, refrigeration systems, and hydronic applications, offering efficient heat exchange in both residential and commercial systems
| Construction | Fully brazed, no gaskets |
|---|---|
| Body material | 316L stainless steel |
| Braze material | 99.9% copper |
| Port sizes | 1-1/4" NPT (5"×12"), 2" NPT (10"×20"), 3" Flange NPT (12"×31") |
| Plate quantity options | 30 / 60 / 100 |
| Design pressure | 435 PSI max (test pressure 652 PSI min) |
| Design temperature | -256°F to 437°F |
- Construction
- Fully brazed, no gaskets
- Body material
- 316L stainless steel
- Braze material
- 99.9% copper
- Port sizes
- 1-1/4" NPT (5"×12"), 2" NPT (10"×20"), 3" Flange NPT (12"×31")
- Plate quantity options
- 30 / 60 / 100
- Design pressure
- 435 PSI max (test pressure 652 PSI min)
- Design temperature
- -256°F to 437°F
Answers
Frequently asked questions
What is the APOLLO Brazed Plate Heat Exchanger used for?
The APOLLO Brazed Plate Heat Exchanger is a general-purpose water-to-water heat exchanger for heat pumps, boilers, chillers, refrigeration, and hydronic systems. It transfers heat between separate circuits without mixing them.
How is a brazed plate heat exchanger different from a gasketed plate exchanger?
The APOLLO model uses fully brazed construction with no gaskets. That means there are no gasket sets to replace as part of routine maintenance, making it a compact option for general water-to-water heat transfer.
What materials are used in this brazed plate heat exchanger?
The body is made from 316L stainless steel and the plates are joined with 99.9% copper braze. Confirm that the construction is compatible with the fluids, temperatures, and operating conditions in your system.
What port sizes and plate counts are available?
The available options include 1-1/4-inch NPT ports on a 5-by-12-inch size, 2-inch NPT ports on a 10-by-20-inch size, and 3-inch flange NPT ports on a 12-by-31-inch size. Plate quantity options are 30, 60, and 100 plates.
How do I size a brazed plate heat exchanger?
Select port size based on the connection and flow requirements, then select plate quantity based on the heat-transfer capacity required by the application. Final sizing should account for the system load, fluids, flow rate, pressure, and temperature; a specialist should confirm the selection.
Can this heat exchanger be used for refrigeration?
The APOLLO Brazed Plate Heat Exchanger is documented for refrigeration applications as well as heat pumps, boilers, chillers, and hydronic systems. Confirm refrigerant, pressure, temperature, flow, and material compatibility with a specialist before ordering.
What pressure and temperature range does it support?
The documented design pressure is up to 435 PSI, with a minimum test pressure of 652 PSI. The documented design temperature range is -256°F to 437°F. Verify the complete operating conditions for your installation before selecting a model.
Does the APOLLO Brazed Plate Heat Exchanger include a manual?
No published manual is currently available for this product. Contact an MBTEK specialist for installation, compatibility, and sizing questions before ordering.
