PHOENIX 35, Compact Pellet Boiler, 120K BTU

PHOENIX 35, Compact Pellet Boiler, 120K BTU

FOR COMMERCIAL USE ONLY

Heat: 4500 ft²
Weight: 794 lbs
Width: 24 ¾'', Depth: 25 ¼'', Height: 59 ½''
Hopper volume: 240Lbs of pellets
Made in Europe
Standards: CSA/B415.1-10 & CSA/B-366.1-11

OUR MOST EFFICIENT AND TECHNOLOGICALLY ADVANCED UNIT TO THIS DATE. UP TO 96% EFFICIENCY

$6,150.00

People watching this item right now
Out of stock
Features
Specs
Reviews/Q&A
Manual

PHOENIX Compact Pellet Boiler

  • High Efficiency

    86% efficiency with pure wood pellets.

  • Eco-Friendly

    Uses 100% natural wood pellets without additives.

  • Durable Construction

    Robust steel water jacket for long-lasting performance.

  • Easy to Use

    Touchscreen interface for simple operation.

  • Self-Cleaning

    Automatic cleaning for efficient maintenance.

  • Safe Operation

    Adheres to safety standards for reliable heating.

High Efficiency

With an impressive energy conversion efficiency exceeding 96%, Phoenix wood pellet boilers significantly reduce fuel consumption and carbon emissions, making them a cost-effective and environmentally friendly heating solution.

Versatile Heating

Capable of heating various spaces, from homes to commercial buildings, these boilers maintain water temperatures up to 90°C and operate at pressures up to 0.15 MPa, ensuring optimal performance in diverse environments.

Safety First

Equipped with multiple safety features, including automatic shut-off mechanisms, these boilers require professional installation to adhere to safety regulations, minimizing fire risks.

Eco-Friendly Fuel

Utilizing 100% natural wood pellets with low ash content, these boilers contribute to a cleaner environment and sustainable heating practices.

Customer video reviews

  • It is wonderful, we finally made it work. I have to say that Allan and Jesus are wonderful.
    ★★★★★

    Jocelyne,

    A Happy Customer
  • The quality is very impressive! Don't over pay for other brands. Allen, Jesus and the MBtek team are very helpful both before and after the sale. Thank you for the great experience guys.
    ★★★★★

    Todd,

    A Happy Customer
  • Product arrived well packed, and undamaged.
    Customer service was great! Very helpful over the phone. Looking forward to doing more business in the future.
    ★★★★★

    Greg,

    A Happy Customer

Frequently asked questions

Where can I find a dealer?

You can speak directly with one of our sales agents via phone, email or text message for more information.

Who will install my heat pump?

Mbtek does not complete the installation. Any HVAC professional will be able to install your purchase. If you require assistance finding one, we are here to help.

Find Installer

Where can I find parts?

Here We have spare parts ready to ship the following business day.

When will I receive my unit?

As soon as the unit is in stock, we will book the shipment following business day. The availability (or ETA) of a specific unit is mentioned on the top of each product page. Depending on your location, delivery can take anywhere from 3 to 12 days

Do I have to pay customs fees if my unit is coming from another country?

No. We take responsibility for these charges.

Are your products shipped in the U.S. or Canada?

It varies for each product. However, we have warehouses in Pennsylvania (U.S.), Alberta (CAN), and Quebec (CAN).

What is the product warranty?

The compressor includes a 5-year warranty.

Need an installer?

We made it easy for you.

Please note that listed installers are independent contractors and not employees of MBTek.
They are skilled professionals familiar with our products and capable of efficient installation.

Any Questions?

Reach out to us

Technical Specifications

Basic Information:

Attribute PHOENIX 18 PHOENIX 35 PHOENIX 50
Heat 2500 ft² 4500 ft² 6200 ft²
Weight 706 lb 794 lb 981 lb
Width 24 ¾" 24 ¾" 32"
Depth 25 ¼" 25 ¼" 34"
Height 57 ¾" 59 ½" 63 ¾"
Hopper volume 200Lbs of pellets 240Lbs of pellets 330Lbs of pellets

Detailed Information:

Attribute PHOENIX 18 PHOENIX 35 PHOENIX 50
Exhaust Gas Pipe 80 mm / 3 in 102 mm / 4 in 102 mm / 4 in
Air Inlet 60 mm / 2.3 in 76 mm / 3 in 76 mm / 3 in
Water Jacket Capacity 38 L / 10 Gal 50 L / 13.2 Gal 86 L / 22.7 Gal
Maximum Water Temperature 90°C / 194°F 90°C / 194°F 90°C / 194°F
Energy Conversion Efficiency > 96% > 96% > 96%
Co Emissions < 300 mg/m³ < 300 mg/m³ < 300 mg/m³
Temperature of Flue Gas ~96°C / 205°F ~90°C / 194°F ~90°C / 194°F
Minimum Chimney Draft 12 Pa / 0.048 in of water 60 Pa / 0.25 in of water 120 Pa / 0.5 in of water
Electrical Consumption (Wmin/Wmax) 240V / 60Hz 240V / 60Hz 240V / 60Hz
Electrical Input Supply (V/Hz) 38 / 10 50 / 13.2 86 / 22.7

Installation and Safety Information:

Installation Requirements Must be performed by qualified personnel following local regulations.
Safety Precautions The boiler should operate with a tightly closed door to prevent combustion risks.
Chimney Specifications The chimney must be airtight, insulated, and constructed from durable materials.
Clearances Minimum distances from walls and combustible materials must be maintained.
Electrical Connections Standard supply is 120V/60Hz, with optional pumps and additional connections as needed.

Reviews

Customer Reviews

Based on 4 reviews
100%
(4)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
C
Christopher Crosbie
Excellent whole home heating

Got a 2400 square foot house with Three zones. 2 zones for the two levels and one for a indirectly fired water heater.
Love this boiler. Thoroughly Clean it once a week and it's happy.

Judge.me YouTube video placeholder
M
Manuel Ferreira III (East Freetown, US)
Received The Pellet Boiler

Boiler delivered, stayed in the garage in its original wrappings until 15 July 2023. Basement prepped, moved boiler into area. Crate and packaging look good, at first glance, everything looks ok. Complete unvailing, inspection and installation being scheduled for middle of Aug 2023. Mbtek kept me informed of shipping and delivery times and dates, happy thus far. Keep you informed.

User picture User picture
R
Robert Brett (Portsmouth, US)
Money saving game changer.

I was due for a new furnace and the prices of heating oil was a challenging thought. I took the leap and ordered/installed a Phoenix 30 after seeing my father in Wisconsin heat his entire home with a pellet stove. I couldn't be happier. The upfront costs of the install will pay themselves off in two years and I will continue to heat my home in New England for the small amount of $900 a year. Well worth it if you are looking to save some money. I love it!

R
Robert Brett
Wish I had installed this years ago!!!

I was able to install the unit myself. It has been running for over a month now and has been rock solid. Wish I had made the switch to this much sooner. Very happy. Wish list: External additional pellet storage with auger delivery.

Technical & User Manuals

This documentation covers many of the topics of interest to end-users and maintenance staff. For any additional inquiries, contact us.

PHOENIX Compact Peller Boiler, Instruction Manual

PHOENIX Compact Peller Boiler, Specification Sheet
