General-Purpose Flow Protection
APOLLO Pool Flow Switch
Adjustable non-mechanical thermal-dispersion flow protection for pool and general industrial water circuits.
Selection
Pool Flow Switch
$174
$12230% OFF
Shipping$80Free
Save 30%
- Free shipping
- Secure checkout
Need help choosing?
Product details
- Non-mechanical thermal-dispersion design
- Adjustable setpoint from 0.2–10 GPM
- 6 LED status indicators for at-a-glance diagnostics
- Relay output rated for 5A contact switching
APOLLO Pool Flow Switch
Designed in the USA.
High-performance thermal dispersion flow switch designed to provide reliable flow proving without moving parts, pressure drop, or the frequent failures common with traditional paddle-style flow switches.
Key Benefits
- Non-mechanical design with no moving parts for long-term reliability
- Provides accurate flow detection with adjustable field-set flow rate
- Operates without creating pressure drop in the system
- Suitable for a wide range of applications including boilers, water heaters, chillers, and transfer systems
- Visual status indication through 6 integrated LED indicators
- Includes both normally open and normally closed outputs for flexible integration
Applications
- Boiler flow proving
- Hot water heaters
- Chillers
- Liquid transfer systems
- Any pipe size requiring non-mechanical flow detection
Specifications
- Detection Range: 0.2 to 10 GPM
- Output Signal: Relay
- Relay Contact Rating: 5A
- Power Supply: 12 to 24VAC/DC
- Warm-Up Time: 10 seconds
- Response Time: 1 to 3 seconds
- Working Pressure: 1500 psi
- Working Temperature: -5°F to 200°F
- Connection Size: 1/2" NPT
- Probe Length: 1 1/4 inches
- Cable Length: 17 ft
- Protection: Thermal cut-off protection in empty pipe
Compare to Dwyer TDFS2-1-P-06, Fluid Components FCI FLT 93, Omega FSW-433, Johnson Controls F261KEH-V01C, Taco IFS01BF-1 / IFS01BR-1, Caleffi 626600A, McDonnell & Miller FS1 / FS1-J, Watts FS-204W, Siemens QVE1900U, Hydrolevel FS200 / FS204.
| Type | Non-mechanical thermal-dispersion, no moving parts |
|---|---|
| Setpoint range | Adjustable 0.2–10 GPM |
| Status indicators | 6 LED |
| Relay output | 5A contact rating |
| Power | 12–24VAC/DC |
| Connection | 1/2" NPT |
| Max pressure | 1500 PSI |
| Temperature range | -5°F to 200°F |
| Warm-up time | 10 seconds |
| Response time | 1–3 seconds |
| Protection | Thermal cut-off for empty-pipe conditions |
- Type
- Non-mechanical thermal-dispersion, no moving parts
- Setpoint range
- Adjustable 0.2–10 GPM
- Status indicators
- 6 LED
- Relay output
- 5A contact rating
- Power
- 12–24VAC/DC
- Connection
- 1/2" NPT
- Max pressure
- 1500 PSI
- Temperature range
- -5°F to 200°F
- Warm-up time
- 10 seconds
- Response time
- 1–3 seconds
- Protection
- Thermal cut-off for empty-pipe conditions
