Apollo Parts - Apollo Air to Water
For Generation 2022 and before:
1 - Main PCB
2 - Display controller
3 - Controller terminal
4 - Connecting line of controller
5 - DC frequency converter 25 A, 220VAC 1PH
6 - Outlet water temperature sensor
7- Electronic expansion valve, main valve
8 - FAN motor
9 - Water flow switch
3 - Controller terminal
4 - Connecting line of controller
5 - DC frequency converter 25 A, 220VAC 1PH
6 - Outlet water temperature sensor
7- Electronic expansion valve, main valve
8 - FAN motor
9 - Water flow switch
10 - DHW Sensor
For Generation 2023:
Display Controller
Display Touchscreen Controller
Fan BladeDisplay Touchscreen Controller
Fan DC Motor
Drive Board
Carel Electric Control
Evaporator Assembly
Heat Exchanger Assembly
Four-Way Valve
Main EEV
Economizer
Auxiliary EEV
Compressor
DHW Sensor
Pool Sensor
WiFi Pool Thermostat
24VAC Relay
COM Card (Master&Slave)
